Structural Features of New Type Membrane Switch Panel

The membrane switch panel of the present invention is the key molding structure of the membrane panel, which can be combined with the corresponding control panel. A combination that can be controlled by pressing and touching is formed; a punch-made panel replaces each button to open the mold, and is individually manufactured and combined. Each installation combination can save a lot of manufacturing costs and labor costs, with multiple economic benefits.

The membrane switch panel of the utility model is punched from membrane switch sheets into connected sheet buttons, which are divided and arranged by hollow lines, and have appropriate pressing and recovery elasticity. Same as unlinkable keys. , directly hollow out the text, numbers or symbols on the surface of each button, and then paste a piece of light-transmitting film on the bottom surface of each button.

The main performance characteristics of the key forming structure of the membrane switch panel:

1. A membrane switch panel key forming structure is characterized in that the membrane switch sheet is punched into a sheet-like key shape, and the sheet-like key shape is divided and arranged with a hollow line, and has suitable pressing and recovery elasticity, and the hollow line cuts each adjacent. of. . Arrangement of worksheet keys that cannot be linked when pressed.

2. Dig out numbers, characters or symbols directly on the surface of each chip button, and then paste a piece of light-transmitting film on the bottom surface of each chip button, and seal it with a light-transmitting film. with symbols.
